coils, strips, foils, tubes, piping, plates, bars, caps, can stock, building construction and automotive
3xxx
F, O, H14, H16, H18, H22, H24, H26
.5 - 12
.020 - .450"
50 - 1800
2.0 - 72"
Up to .125" / 3mm
coils, strips, foils, tubes, piping, plates, bars, caps, can stock, building construction and automotive
5xxx
F, O, H14, H16, H18, H22, H24, H26
.5 - 12
.020 - .450"
50 - 1800
2.0 - 72"
Up to .125" / 3mm
coils, strips, foils, tubes, piping, plates, bars, caps, can stock, building construction and automotive
Specialty Coil
Alloy
Tempers
Gauge Range (mm)
Gauge Range (inches)
Width Range (mm)
Width Range (inches)
Tension Leveled
Special Features
Applications
1060
H18
3.5 - 6.8
.14 - .27"
650 - 1500
25.5 - 59"
Drill Sheet
3003
H12, H14, H16
.45 - 2
.018 - .080"
1828 - 2641
72 - 104"
Yes
Flatness, Small coil weights available
Floating & Trailer Roof, Dome
5052
HX2, HX4, HX6
1.6 - 3
.063 - .125"
1828 - 2387
72 - 104"
Yes
Flatness
Freashwater Fishing & Pontoon Boat
5054
H32, H34
3 - 6.3
.125 - .249"
1219 - 2133
48 - 84"
No
Surface Finishes
Trailer Roof Coil and Sheet
6xxx
F, T3, T4, T5, T6, T42, T62, T73, T74
3 - 6.3
.019 - 5.9"
1000 - 1600
39.4 - 63"
Up to .125" / 3mm
Auto plate: car shell, body
Tread Plate and Coil
Alloy
Tempers
Gauge Range (mm)
Gauge Range (inches)
Width Range (mm)
Width Range (inches)
Tension Leveled
Special Features
Applications
3003
0, H22/H24
1.6 - 12.7
.063 - .5"
914 - 1524
36 - 60"
W/A
Diamond
Truck and Trailer, Achitecture, Tool Box
5052
0 and H32
1.6 - 12.7
.063 - .5"
914 - 1524
36 - 60"
W/A
Diamond,
5 Bar
Structural, Marine, Trailer
5754
0 and H32
1.6 - 12.7
.063 - .5"
914 - 1524
36 - 60"
W/A
Diamond,
5 Bar
Structural, Marine, Trailer
Note: Almost all alloys available. We can offer a wide range of products from .001 – ½” thickness, up to 104” width in alloys groups of 1, 3, 5, 6xxx series
